X46E5

X46E45

X46E45 series infrared thermal imager, ir thermal imaging camera uses a 12 μm vanadium oxide uncooled infrared focal plane detector, infrared cam has a high-performance infrared lens, an excellent imaging processing circuit, and is embedded with advanced image processing algorithms. It has the characteristics of small size, low power consumption, fast startup, and excellent imaging quality.

the X46E45 series infrared thermal imager module, high speed infra red camera fully considers the requirements of high and low temperature working performance to ensure that the whole machine has excellent environmental adaptability.

PRODUCT FEATURES

It has all-weather passive thermal imaging function, has strong smoke penetration performance, and can be used in a wide range of ambient temperature.

The high frame rate design enables the operator to observe fast-moving targets.

It uses a 12 μm vanadium oxide uncooled infrared focal plane detector

It has a high-performance infrared lens, an excellent imaging processing circuit, and is embedded with advanced image processing algorithms.

a high-performance infrared lens, an excellent imaging processing circuit, and is embedded with advanced image processing algorithms.

Specifications

Detector Type	Vanadium Oxide Uncooled Detector
Number of pixels	640 × 512
Pixel spacing	1 2 μm
Wavelength range	8～14μm
Thermal sensitivity ( NETD)	< 35 mk (@25°C , F# = 1. 0 )
Frame rate	50 fps
Imaging time	<5 s
Calibration method	Support automatic correction (timing, temperature difference), manual and background correction
Non-uniformity correction	Shutter Correction Technology
False Color Mode	Black hot, white hot, red hot, fusion
Image detail enhancement	support
Contrast, brightness	support
AGC Mode	Automatic mode
Noise Reduction	support
Electronic Amplification	×1, ×2, ×4, ×8
Bad pixel repair	support
Mirror	Off, Vertical, Horizontal, Center
Image Output	8-bit BT.656 (720*576)
Parameter preservation	support
cursor	support
menu	support
Video Interface	8-bit BT.656
Input power voltage	12VDC
Communication interface	UART
Steady-state power consumption	< 2 W
Operating temperature	-40℃～60℃
Storage temperature	-50℃～ 85 ℃
Vibration shock level	750g / 1 ms
humidity	˂ 90% RH
focal length	Athermal 45 mm (F# 1.2 )
Focus mode	Manual
Field of view	9.7 ° × 7.8 ° ( horizontal field of view × vertical field of view )
Spatial resolution	0.267 mrad
Dimensions	Ø 46 mm × 69.5 mm
weight	< 130 g
Mounting holes	Two M3× 5 on the bottom
